Micro Thermocouple Connectors and Accessories

Micro size - Tiny footprint for applications where space is a premium
Thermoplastic rated to 220°C
Available in all thermocouple types
ANSI MC96.1 or IEC 60584.3 Colour Codes (DIN and JIS colours are also available)
Accepts stranded or solid wires up to 0.5mm diameter (0.2mm²)
High purity thermocouple alloys used for male pins and female socket connections
Easy wiring via lipped washer

M11 - Micro Plug rated to 220°C

Type K ANSI Illustrated (M11K-A)

Type T ANSI Illustrated (M20T-A)

Type R/S ANSI Illustrated (M29RS-A)

Application
This adaptor can be crimped onto a mineral insulated cable or metal tube so it may then be attached to a micro connector.

Stainless steel adaptors may also be brazed. They can also be used to crimp some soft materials such as PVC or PFA wires and cables.

Construction
Nickel Plated Brass, Brass or Stainless Steel.
